General Information
Brand
Greenlee
Part Number
DM-810A
Product Type
Digital Multimeter
What’s Included
(1) 9V Battery, Bead Temperature Probe (DM-820A, DM-830A Only, 400°F/204°C Max), Test Leads, Protective Boot, Carrying Case
Packaging
Retail
Country of Origin
Taiwan
UPC
783310087434
California Residents
Proposition 65 Warning
Physical Characteristics
Weight
1.06 kg
2.34 lb
Details
Measurement Standard
CAT IV, C/UL US Listed, TRUE RMS, CE Listed
Features
True RMS for no-compromise accuracy
Measures voltage, current, resistance, capacitance and frequency
Tests continuity and diodes
Backlit LCD with dual 10,000 count displays
BeepJack warns when test leads are incorrectly inserted in current measurement terminals
Automatic and manual range selection
Relative offset mode to see changes in measurements
Data hold
Use optional USB interface DMSC-9U for direct-To-PC logging
Measures voltage, current, resistance, capacitance and frequency
Tests continuity and diodes
Backlit LCD with dual 10,000 count displays
BeepJack warns when test leads are incorrectly inserted in current measurement terminals
Automatic and manual range selection
Relative offset mode to see changes in measurements
Data hold
Use optional USB interface DMSC-9U for direct-To-PC logging
Amperage Measurement: 600, 6000μA; 60, 600mA; 6, 10A
Conductance: 99.99 nS
Measurement Category: CAT IV, 1000 V
Voltage
60, 600 mV, 9.999, 99.99, 999.9 V
Capacitance
60, 600nF; 6, 60, 600μF; 6, 25 mF
Resistance (Ohms)
600Ω; 6, 60, 600 kΩ; 6, 60 MΩ
Frequency
15Hz- 50kHz Sine Wave, 5Hz – 1MHz Logic Level Square Wave
Batteries
(1) 9 V
Display Type
Backlit LCD With Dual 10,000 Count
Temperature Range
K Type, -58 To 1832°F (-50 To 1000°C)
